| 구분 | E07 | |||||
|---|---|---|---|---|---|---|
| 1500 | 1800 | 2400 | 3600 | 5400 | ||
| 규격 (mm) |
W(폭) | 1500 | 1800 | 2400 | 3600 | 5400 |
| D(깊이) | 1200 | |||||
| H(높이) | 2400 | |||||
| External & Interior | SUS 304 1.0~1.5mm H/L Finished | |||||
| Door | 상/하 & 좌/우 Sliding door type | |||||
| Door Sash | SUS 304 1.0~1.2mm H/L Finished | |||||
| Glass | Tempered safety glass 5mm | |||||
| Concent | 110V x 2EA/220V x 2EA | |||||
| Lamp | LED Lamp 20W | |||||
| Lamp & Blower switch | Selector Type | |||||
| Duct outlet | 200 / 250 / 300ø | |||||
| Air curtain fan | Option | |||||
| Blower | Option <실내형 / 실외형> | |||||
| Option | Support frame / Air velocity monitor / Auto damper / Safety glass film | |||||
