| 구분 | E03 | |||||
|---|---|---|---|---|---|---|
| 1600 | 1900 | 2200 | 2500 | 2800 | ||
| 규격 (mm) |
W(폭) | 1600 (1200+400) |
1900 (1500+400) |
2200 (1800+400) |
2500 (2100+400) |
2800 (2400+400) |
| D(깊이) | 800 | |||||
| H(높이) | 2350 | |||||
| External | SUS 304 1.0~1.2mm H/L Finished | |||||
| Interior | SUS 304 1.0mm H/L Finished | |||||
| Baffle | SUS 304 1.0mm H/L Finished | |||||
| Work top | SUS 304 1.5mm H/L Finished | |||||
| Door | Tempered safety glass 5.0mm <상,하 슬라이딩> | |||||
| Cabinet | 40x40 SUS Pipe & SUS 304 1.0mm H/L Finished | |||||
| Cabinet Door | SUS 304 1.0mm H/L Finished | |||||
| Concent | 2구 접지형 110V/220V 각각 2ea씩 부착 | |||||
| Light | LED Lamp 20W X 1EA | |||||
| Lamp & Blower switch | Selector Type | |||||
| Gas & Water | 3EA | |||||
| Duct outlet | 200 / 250 / 300ø | |||||
| SUS resin & drain | 1EA | |||||
| Blower | Option <실내형 / 실외형> | |||||
| Option | Support frame / Air velocity monitor / Auto damper / Safety glass film | |||||
