| 구분 | P04 | |||||
|---|---|---|---|---|---|---|
| 1600 | 1900 | 2200 | 2500 | 2800 | ||
| 규격 (mm) |
W(폭) | 1600 (1200+400) |
1900 (1500+400) |
2200 (1800+400) |
2500 (2100+400) |
2800 (2400+400) |
| D(깊이) | 800 | |||||
| H(높이) | 2200 | |||||
| External | PVC/P.P 8T White color & PVC 3.0T extrusion moulding | |||||
| Interior | PVC/P.P 5-10T White color | |||||
| Work top | PVC/P.P 10T White color | |||||
| Door | Up/Down Sliding door type | |||||
| Door sash | PVC 5T(2매) White color | |||||
| Glass | Clear PVC 5T | |||||
| Cabinet | PVC/P.P 5-8T white color | |||||
| PP resin & drain | 1EA | |||||
| Concent | 110V X 4EA / 220V X 4EA | |||||
| Lamp | LED Lamp 20W X 1EA | |||||
| Lamp & Blower switch | On / Off | |||||
| Gas & Water | 3EA | |||||
| Air Curtain Fan | Option | |||||
| Duct outlet | 200 / 250 / 300ø | |||||
| Blower | Option <실내형 / 실외형> | |||||
| Option | Support frame / Air velocity monitor / Auto damper /Safety glass film | |||||
